PSA Nitrogen Generator
[ Edit: admin     Created Date: 2013-01-23   Readed Times:      Font:big middle small]




Product Description
BROTIE PSA Nitrogen Generator
Principles:

Customized PSA nitrogen generator, purity from 95%-99.999% with no purification system, capacity from 1Nm3/h-5000Nm3/h, pressure from 0.1bar to 200bar, uses carbon molecular sieve as sorbent, produces nitrogen by making use of the PSA principle. Professional energy saving design provided with each of BROTIE nitrogen generator system, low air consumption means more economical for customers.

The BRO-CONTROL system is provided, all the parameters can be read and the operation can be actualized by one touch only. Alarming system can work automatically when the purity, the capacity and pressure is lower than required, it means more reliable and more humanistic for customers.

Applications:

1. Metallurgy: For anneal protection, agglomeration protection, nitrogenizing, furnace washing and blowing, etc. Used in fields such as metal heating treatment, powder metallurgy, magnetic material, copper process, metallic mesh, galvanized wire, semiconductor, etc.

2. Chemical and new material industries: For chemical material gas, pipeline blowing, gas replacement, gas protection, product transport, etc. Used in fields such as chemical, urethane elastic fiber, rubber, plastic, tyre, polyurethane, biological technology, intermediate, etc.

3. Electronic industry: For encapsulation, agglomeration, anneal, deoxidization, storage of electronic products. Used in fields such as peak welding, circumfluence welding, crystal, piezoelectricity, electronic porcelain, electronic copper tape, battery, electronic alloy material, etc.

All the models can be customized, for more information, please contact directly.
Capacity
(Nm 3 /h)
Purity
(%)
Model
Construction
Dimensions
(mm)
Inlet& Outlet
Weight
(Kg)


5
95
CA-A-5
Four towers
570*450*1300
G1/4; G1/4
253

99
CA-B-5
Four towers
580*460*1450
G1/4; G1/4
295

99.5
CA-C-5
Four towers
1000*900*1200
DN20; G1/2"
370

99.9
CA-D-5
Four towers
1000*900*1500
DN20; G1/2"
431

99.99
CA-E-5
Four towers
1200*1100*1350
DN20; G1/2"
535

Four towers
1100*1050*1400
DN20; G1/2"
493

99.999
CA-F-5
Four towers
1300*1200*1700
DN25; G1/2"
698

Two towers
1100*600*1600
DN25; G1/2"
510

10
95
CA-A-10
Four towers
1000*900*1400
DN20; G1/2"
414

99
CA-B-10
Four towers
1100*1050*1400
DN20; G1/2"
485

99.5
CA-C-10
Four towers
1100*1050*1650
DN20; G1/2"
510

99.9
CA-D-10
Four towers
1200*1150*1850
DN20; G1/2"
624


Two towers
1100*600*1600
DN20; G1/2"
451

99.99
CA-E-10
Four towers
1400*1300*1600
DN25; G1/2"
788

Two towers
1200*650*1410
DN25; G1/2"
565

Four towers
1300*1250*1600
DN25; G1/2"
762

Two towers
1200*650*1400
DN25; G1/2"
552

99.999
CA-F-10
Four towers
1500*1400*1850
DN25; G1/2"
1098

Two towers
1300*700*1850
DN25; G1/2"
838

15
95
CA-A-15
Four towers
1000*900*1550
DN20; G1/2"
426

99
CA-B-15
Four towers
1100*1050*1580
DN20; G1/2"
534

99.5
CA-C-15
Four towers
1100*1050*1680
DN20; G1/2"
550

99.9
CA-D-15
Four towers
1300*1200*1700
DN25; G1/2"
666


Two towers
1200*600*1500
DN25; G1/2"
468

99.99
CA-E-15
Four towers
1500*1400*1650
DN25; G1/2"
991

Two towers
1300*750*1550
DN25; G1/2"
711

Four towers
1400*1300*1700
DN25; G1/2"
882

Two towers
1200*650*1700
DN25; G1/2"
650

99.999
CA-F-15
Four towers
1700*1550*2050
DN40; G1/2"
1349

Two towers
1400*750*1960
DN40; G1/2"
935

Four towers
1900*1750*2150
DN40; G1/2"
1860

Two towers
1750*850*2150
DN40; G1/2"
1341

20
95
CA-A-20
Four towers
1100*1050*1400
DN20; G1/2"
498

99
CA-B-20
Four towers
1200*1150*1550
DN20; G1/2"
597

99.5
CA-C-20
Four towers
1200*1150*1600
DN20; G1/2"
611


Two towers
1100*600*1600
DN20; G1/2"
435

99.9
CA-D-20
Four towers
1400*1300*1650
DN25; G1/2"
845


Two towers
1300*650*1600
DN25; G1/2"
621

99.99
CA-E-20
Four towers
1500*1400*2050
DN40; G1/2"
1192

Two towers
1300*700*1950
DN40; G1/2"
848

Four towers
1500*1400*1800
DN25; G1/2"
1059

Two towers
1300*700*1700
DN25; G1/2"
780

99.999
CA-F-20
Four towers
1800*1650*2100
DN40; G1/2"
1582

Two towers
1550*800*2100
DN40; G1/2"
1119

Four towers
2100*1950*2160
DN40; G1/2"
2320

Two towers
1800*950*2160
DN40; G1/2"
1714

25
95
CA-A-25
Four towers
1100*1050*1680
DN25; G1/2"
558

99
CA-B-25
Four towers
1300*1200*1650
DN25; G1/2"
675


Two towers
1100*600*1650
DN25; G1/2"
475

99.5
CA-C-25
Four towers
1300*1200*1700
DN25; G1/2"
687



Two towers
1100*600*1700
DN25; G1/2"
478

99.9
CA-D-25
Four towers
1400*1300*1850
DN25; G1/2"
930


Two towers
1200*600*1820
DN25; G1/2"
645

99.99
CA-E-25
Four towers
1600*1500*2050
DN40; G1/2"
1323

Two towers
1450*750*1800
DN40; G1/2"
932

Four towers
1500*1400*2050
DN40; G1/2"
1217

Two towers
1300*700*1950
DN40; G1/2"
857

99.999
CA-F-25
Four towers
1900*1750*2170
DN40; G1/2"
1876

Two towers
1600*850*2170
DN40; G1/2"
1336

Four towers
2200*2000*2460
DN40; G1/2"
2703

Two towers
1800*950*2060
DN40; G1/2"
1992

30
95
CA-A-30
Four towers
1200*1150*1600
DN25; G1/2"
627


Two towers
1100*600*1450
DN25; G1/2"
426

99
CA-B-30
Four towers
1400*1300*1500
DN25; G1/2"
772


Two towers
1200*650*1400
DN25; G1/2"
543

99.5
CA-C-30
Four towers
1400*1310*1550
DN25; G1/2"
813


Two towers
1200*650*1450
DN25; G1/2"
567

99.9
CA-D-30
Four towers
1500*1400*1700
DN40; G1/2"
1049


Two towers
1300*700*1600
DN40; G1/2"
751

99.99
CA-E-30
Four towers
1800*1650*2000
DN40; G1/2"
1498

Two towers
1500*800*1900
DN40; G1/2"
751

Four towers
1700*1550*1980
DN40; G1/2"
1367

Two towers
1400*750*1980
DN40; G1/2"
951

99.999
CA-F-30
Four towers
2000*1850*2120
DN50; G1"
2099

Two towers
1750*900*2110
DN50; G1"
1525

Four towers
2300*2100*2550
DN40; G1"
3090

Two towers
1900*1050*2550
DN40; G1"
2275

40
95
CA-A-40
Four towers
1300*1200*1750
DN40; G1"
743


Two towers
1100*600*1700
DN40; G1"
502

99
CA-B-40
Four towers
1400*1300*1900
DN40; G1"
968


Two towers
1200*650*1800
DN40; G1"
671

99.5
CA-C-40
Four towers
1400*1300*1900
DN40; G1"
985


Two towers
1200*650*1800
DN40; G1"
685

99.9
CA-D-40
Four towers
1700*1550*1850
DN40; G1"
1242


Two towers
1400*750*1750
DN40; G1"
868

99.99
CA-E-40
Four towers
1900*1750*2100
DN40; G1"
1842

Two towers
1650*850*2100
DN40; G1"
1323

Four towers
1800*1650*2100
DN40; G1"
1672

Two towers
1550*800*2100
DN40; G1"
1178

99.999
CA-F-40
Four towers
2200*2000*2400
DN50; G1"
2543

Two towers
1800*950*2400
DN50; G1"
1920

Four towers
2500*2300*2650
DN40; G1"
3889

Two towers
2100*1150*2650
DN40; G1"
2945

50
95
CA-A-50
Four towers
1400*1300*1650
DN40; G1"
881


Two towers
1200*650*1550
DN40; G1"
617

99
CA-B-50
Four towers
1500*1400*1850
DN40; G1"
1115


Two towers
1300*700*1800
DN40; G1"
790

99.5
CA-C-50
Four towers
1500*1400*1900
DN40; G1"
1139


Two towers
1300*700*1750
DN40; G1"
806

99.9
CA-D-50
Four towers
1750*1600*1850
DN40; G1"
1418


Two towers
1500*800*1750
DN40; G1"
1012

99.99
CA-E-50
Four towers
2000*1850*2150
DN50; G1"
2133

Two towers
1750*900*2100
DN50; G1"
1557

Four towers
1900*1750*2170
DN40; G1"
1901

Two towers
1600*850*2170
DN40; G1"
1366

99.999
CA-F-50
Four towers
2400*2200*2350
DN50; G1"
2679

Two towers
2000*1100*2350
DN50; G1"
2045

Four towers
2700*2450*2900
DN50; G1"
4415

Two towers
2200*1200*2900
DN50; G1"
3288
