Products Descriptions:

1. Vibration isolation mount technology ensure smooth and quiet operation

2. Multi-auto alarm associate high temperature shut down protection system

3. Easy to maintain with off the shelf parts

4. Easy to operate with detail instruction manual

5. Top grade diesel engines are used to ensure minimal emission to environment



Feature:

1、Compressor series is the German company GHH, Italian head imported from TMC. From Europe's leading-edge technology, optimized line design, high accuracy, low internal leakage, high efficiency, low power, low noise and high reliability characteristics.

2、The strong power province oil, the maintenance are simple, select Commings, in the jade firewood engine series the maturest type, the reliability are high, oil-consuming is lowand maintenance is simple and economical.

3、Deluxe luminous microcomputer control panel, has powerful function, perfect protection design and layout of the control panel of the valve to control the running state.

4、Double pressure supplied design, one is equal to two. To meet customer demand for different supply pressure;it owns the functions:internal engine temperature, oil pressure, operation speed, air exhaust over temperature, exhaust pressure auto-protect feature.

5、The contour is artistic, the arrangement is reasonable, the maintenance is extremely convenient, the large-scale quarto gate design, opens the door then carries on the overall check and the maintenance, the air compressor oil filter, the air strainer, the diesel engine oil filter, the air strainer and so on must maintain the maintenance to result in the spare part in the scope at arm's length, reduced the service time and the expense enormously, lengthened machine's running time.

Main Products :

1) Screw Air Compressors ( Air delivery:0.8m³/min -72m³/min;Work pressure:8-13Bar;Power:7.5Kw-400kw)

2) Mining Air Compressors (Air delivery:1.8m³/min-13m³/min ;Work pressure:5-7Bar;Power:11Kw-108Kw)

3) Diesel Driven Portable Screw Air Compressors (Air delivery:6m³/min-39m³ ,Work pressure:7-35Bar )

4) Motor Powered Portable Screw Air Compressors (Air delivery:2m³/min-35m³ ,Work pressure:7-46Bar )

5) Diesel Driven Piston Mining Air Compressors ( Air delivery: 2m³/min-13m³/min, Power: 11-105Kw)



Model	Nominal Pressure(Mpa)	F.A.D(Free Air Delivery)(m3/min)	Oil Content ppm	Diesel Power kW ( HP )	Weight(net excl.fuel) kg	Dimension LxWxH (mm)
42SCY-7	0.7	4	<6	42(65)	780	2110X1500X1620
58SCY-8	0.8	7	<6	58(80)	1550	3140X1740X1900
110SCY-8	0.8	12	<6	110(150)	2480	3120X1630X2290
110SCY-10	1.0	12	<6	110(150)	2480	3120X1630X2290
110SCY-10	1.0	10	<6	110(150)	2480	3120X1630X2290
110SCY-14.5	1.45	8.5	<6	110(150)	2480	3120X1630X2290
140SCY-8	0.8	17	<6	140(180)	3000	3650X1700X2040
138SCY-14.5	0.8/1.45	12.8	<6	140(180)	3000	3350X2060X2350
139SCY-13	1.3	15	<6	140(180)	3000	3650X1700X2040
177SCY-14.5	1.45	15.2	<6	179(240)	3800	3720X1970X2550
178SCY-14.5	1.45	17	<6	179(240)	3800	3720X1970X2550
180SCY-8	0.8	20	<6	179(240)	3800	3720X1970X2550
180SCY -14.5	1.45	17	<6	179(240)	3800	3720X1970X2550

Model	Nominal Pressure (Mpa)	F.A.D(Free Air Delivery)(m3/min)	Oil Content ppm	Diesel Power kW ( HP )	Weight(net excl.fuel) kg	Dimension LxWxH (mm)
177SCY-17	1.7	16	<6	179(240)	3760	3720X1970X2550
188SCY-17	1.7	18	<6	191(260)	3650	3720X1970X2550
191SCY-17(highland)	1.7	18	<6	191(260)	3830	3720X1970X2550
250SCY-17	1.7	22	<6	250(340)	4800	3810X2000X2900
195SCY-19	1.9	19	<6	194(260)	3830	3720X1970X2550
260SCY-21	2.1	22	<6	250(340)	4590	4150X2000X2900
288SCY-22	2.2	27	<6	288(380)	4940	4150X2000X2900
406SCY-25	2.5	33	<6	400(525)	5800	4600x2250x2900
380SCY-25	25	26	<6	QSZ13-C500，500HP/YC6K500L，500HP	5700	4700×2100×2500
370SCY-35	35	21	<6		5700	4700×2100×2500
400SCY-25/35	25（35）	26（21）	<6		5800	4700×2100×2500
380SCY-35	35	26	<6	QSZ13-C550，550HP/YC6K550L，550HP	5800	4700×2100×2850
420SCY-25/35）	25(35)	33(26)	<6		5800	4700×2100×2850
450SCY-25	25	39	<6	KTA19-P630，630HP/C-18 ACERT，630HP	6100	4700×2100×2850
406SCY-35	35	33	<6		6100	4700×2100×2850
450SCY-25/35	25(35)	39(33)	<6		6100	4700×2100×2850
