Oxygen gas (O2) Compressor
.jpg)
|
Model NO.:
|
BRC-O2
|
|
Lubrication Style:
|
Oil-free
|
|
Power Source:
|
AC Power
|
|
Configuration:
|
Portable
|
|
Type:
|
Reciprocating
|
|
Model Number:
|
Brc-O2
|
|
Place of Origin:
|
China
|
|
Compressed Grade:
|
4
|
|
Mute:
|
Yes
|
|
Working Principle:
|
Oil-Free Lubrication Reciprocating Type Booster
|
|
Cooling Type:
|
Wind or Water Cooling
|
|
Power Consumption:
|
1.5-45kw
|
|
Rpm Range:
|
400-800rpm
|
|
Capacity Range:
|
5, 10, 20, 30, 40, 50nm3/H
|
|
Outlet Pressure:
|
150bar
|
|
Export Markets:
|
Global
|
Product Description
BROTIE High Pressure Oil-free Oxygen Compressor(150bar)
This series are designed for oxygen cylinder purpose only.
Model OW-30/4-150
Flow Capacity 30Nm3/h
Compressing Grade 4grades
Inlet Pressure 4bar
Outlet Pressure 150bar
Outlet Temperature 50C
Inlet Size DN40
Outlet Size Customized
Ambient Temperature Normal temperature
Cooling System Water cooling 2t/h
Lubrication No Lubrication
Rotating Speed 400rpm
Power Consumption 11Kw
Weight 940kg
Dimensions 1650*850*1650mm
All parts which contact with O2 gas are made of anti-rot material.
For more information, pleaes do not hesitate to contact.
